Ningbo Hongda Motor Mould Co., Ltd. is a joint-stock private enterprise founded in April 1988. After 19 years of hard work and continuous technological innovation, the company has developed into today's professional development and production of motor iron core stator and rotor sheet motor mould manufacturing center. It is a key backbone enterprise of the China Mould Industry Association, a member unit of the National Standardization Committee, a member unit of the Technical Committee of the China Mould Industry Association, a high-tech enterprise in Zhejiang Province, the director unit of the Ningbo Cold Stamping Mould Committee, and a "Top Ten" technological innovation demonstration enterprise in Cixi City.
1. Talent structure and quantity
The company currently has 528 employees, including 221 professional and technical personnel with college or technical secondary school education, accounting for 42% of the total number of employees. There are 5 senior engineers and deputy senior engineers, including 1 researcher-level senior engineer and 1 person enjoying the government subsidy of the State Council, all of whom are technical leaders in the motor mold industry; there are also 3 senior technicians, all of whom are highly skilled talents with rich practical experience in the motor mold industry; 35 people with intermediate technical titles, all of whom are technical backbones in the company's R&D, design, process and production front lines; 56 people with junior technical titles, all of whom are new skilled talents cultivated by the company. The company has formed a development team of scientific and technological personnel with high academic level and strong professional quality, and a production team with senior technicians as the core with rich practical experience. Compared with the same industry, it has obvious advantages in technical R&D and production talents.
2. Development, production infrastructure and business scale
(1) The scale of the company's motor mold development and production infrastructure ranks first in the industry. The company covers an area of 34,345 square meters and has a construction area of 43,338 square meters; of which: the company's "Cixi Motor Silicon Steel Sheet Cold Stamping Die Engineering Technology Innovation Center" has a construction area of 1,500 square meters, and the production plant has a construction area of 31,639 square meters (18,939 square meters of fully constant temperature production plant).
(2) The original value of fixed assets is 58.65 million yuan, of which the original value of equipment is 38.7 million yuan (the original value of CNC equipment is 21 million yuan).
(3) The output of long-life silicon steel sheet cold stamping dies for medium and small motors reaches 6,000 pairs/year; the output of large, precise, and complex motor cold stamping dies reaches 100 pairs/year; the output of automatic riveting carbide multi-station progressive dies for stator and rotor cores reaches 200 pairs/year.
(4) In 2006, it is expected to complete more than 8,000 pairs of various types of motor molds, with an estimated output value of 100 million yuan and a profit of 40 million yuan.
3. Application areas
The motor molds developed and produced by the company are the most widely used in the motor mold industry. The following industries are mainly involved:
(1) Small and medium-sized motor industry, (2) Large motor industry, (3) Generator industry, (4) Micro motor industry, (5) Micro motor industry, (6) Power tool industry, (7) Household appliance industry, (8) Transformer industry, (9) Permanent magnet motor industry, (10) Automobile industry (11) Aerospace industry, (12) Electronic information industry.
4. Market share
The company's motor mold products are distributed in 29 provinces and cities across the country and exported to Southeast Asia. The market share of motor mold products ranks first in China.
(1) The company's Y, Y2, C02 series long-life motor silicon steel sheet cold stamping dies, large motor fan-shaped precision molds and large motor block precision molds have more than 1,000 users, and the precision multi-station progressive mold quality has more than 200 users, accounting for 70% of the domestic market share of commercial motor molds.
(2) In 2005, the motor mold products achieved sales revenue of 48.2 million yuan, and it is expected that the motor mold products will achieve sales revenue of 60 million yuan in 2006.
5. Varieties and specifications
The varieties and specifications of motor molds developed and produced by the company almost cover the motor products of motor manufacturers in the motor industry and motor manufacturers in various industries. It has become a unique domestic company that can produce large, medium, small and micro motors at the same time.
(1) Motor punching: blanking die, stator slot punching die, rotor slot punching die, stator full-complex die, rotor full-complex die, armature full-complex die, outer rotor, stator complex drop die, separation compound die, high-speed single-slot punching die, high-speed continuous punching and cutting die, fan-shaped piece precision block die, main pole magnetic piece precision block full-complex die, large blade precision block full-complex die, large precision block blanking die;
(2) Motor core: multi-position progressive die for cross-excitation motor, multi-position progressive die for household motor, multi-position progressive die for cover motor, multi-position progressive die for permanent magnet motor, multi-position progressive die for plastic-sealed motor, multi-position progressive die for EI sheet, multi-position progressive die for core block, multi-position progressive die for strip material rolling.
(3) Motor mold specifications: Ф5～Ф1500, generator set over 10 meters.
6. Production scale and speed
Based on the advanced professional technical foundation and standardization system as technical guarantee, the "E-Ma mold production and manufacturing management system" is adopted to realize the information management of motor molds. The parallel operation of motor molds from design, material preparation, processing to assembly has created a "high speed", "high efficiency" and "high quality" large-scale production model of motor mold products. The company's mold design is fast and the production cycle is short, which is second to none in the motor mold industry. The annual output of long-life motor silicon steel sheet cold stamping dies is 6,000 pairs, 60% of the products are standard molds available from stock, and the average delivery cycle of 40% of non-standard molds is 20 days; the annual output of large, precise and complex cold stamping dies for motor stamping is 100 pairs, with an average delivery cycle of 40 days; the annual output of multi-station progressive dies for motor cores is 200 pairs, with an average delivery cycle of 50 days.
7. Quality level
a) Multi-station progressive die for motor core
This die is a mechatronic carbide multi-station progressive die for motor core automatic lamination, with an accuracy of 2μm, a step accuracy of 3μm, a block accuracy of 1μm, a double rotation accuracy of 1', a surface roughness of Ra0.10~0.40μm, and a die frame parallelism of 0.01 mm/1000mm. The die is used on a high-speed punch press at 300~500 times per minute, and has functions such as automatic stamping, lamination, twisting groove, grouping, and rotation. The die is equipped with electronic monitoring devices such as cylinders, solenoid valves, and misfeed detection. The die has an 80% one-time mold trial success rate, 300~500 punches/minute, an average single sharpening of 1.8 million punches, and a total life of 200 million times. The technical level is at the advanced technical level of similar molds in China, and is comparable to the technical level of similar molds abroad, and all parts are fully interchangeable. The mold can replace imports.
b) Single-station compound die for motor punching
The die adopts detachable precision die frame technology, modern punch bonding process, CNC precision machining and testing technology. The die has the characteristics of convenient sharpening, high guiding accuracy, good punch stability, uniform blanking gap, and long die life. The one-time die trial success rate is 95%; the average single sharpening is 15,000 punches; the total life is 1.5 million punches. The quality and technical level of the Y, Y2, C02 series long-life motor silicon steel sheet cold punching die, large motor fan-shaped and large motor block precision blanking die produced by the company are at the leading level in China.
8. R&D capabilities
The company has established a relatively complete technology and R&D system. It has a group of scientific and technological development teams with high academic level, strong professional quality and rich practical experience. It has formed professional technical system documents such as "Hongda Die Design Specifications", "Hongda Die Standardized Parts", "Hongda Die Typical Structure", "Hongda Die Typical Layout", "Hongda Die Standard Parts Manual", "Hongda Die Process Specifications", and "Hongda Die Inspection Specifications". We keep track of advanced technologies at home and abroad, digest and absorb advanced technologies from Europe, America and Japan, and transform them into professional technologies of "Hongda". The "Intelligent CAD System for Progressive Dies of Motor Cores" under development will greatly improve design efficiency and quality. Compared with the same industry, the motor molds developed and produced by the company have the most complete varieties, the most specifications, the highest standardization, the strongest professional level and the leading technical level. Many motor mold products have won the honors of "National New Products" and "Molds with International Level".
The company allocates 5% to 8% of its sales revenue each year as research and development funds for the development of new products to carry out research and development of new products. The multi-station progressive die for the motor core has developed a progressive die of 1900×900×420 (length×width×height) and a weight of more than 3 tons; the single-station compound die for the motor punching has developed a die of 1400×1400×380 (length×width×height) and a weight of more than 2.5 tons.
The motor mold products mainly developed and produced by the company have been rated as "domestic high-quality molds" and "national new products" by the China Mold Association for seven consecutive years, and the motor mold products are deeply favored by users. The "Large Precision Cold Punching Die for Long Stator Motor Core Punching Sheets of Maglev Trains" developed and manufactured by the company was rated as a "national new product" by the China Mold Association, and was rated as an internationally advanced mold by the expert group at the 9th China Mold Technology and Equipment Exhibition, and passed the technical appraisal of the Ningbo Economic Commission. The newly developed "Progressive Die for Long Stator Core of Maglev Train Linear Motor" has obtained a national utility model patent. The "Automatic Riveting Hard Alloy Multi-station Progressive Die for Motor Core" developed and manufactured by the company was rated as a "national new product" by the China Mold Industry Technical Committee, and was rated as a "mold with international standards" at the 10th China International Mold Technology and Equipment Exhibition. It was awarded the first prize of "Precision Mold" at the 11th China International Mold Technology and Equipment Exhibition, and passed the Ningbo New Product Production Appraisal. The long-life series of motor silicon steel sheet cold punching dies were awarded the "Second Prize for Science and Technology Progress in Zhejiang Province".
9. Brand and reputation
Since its establishment, the company has paid attention to the image promotion of the company. Since 1990, it has invested an average of 300,000 yuan per year to promote the image and advertisement of "Hongda" to the society, and continuously enhance the influence and reputation of "Hongda" in the society. The company's motor mold products have been widely recognized by the society and favored by the majority of users. "Hongda Mold" has won the "Famous Trademark of Cixi City" and "Famous Trademark of Ningbo City". The image of "Hongda" has brought huge intangible assets and social benefits to the company.
10. Talent training and construction
The company has established "Hongda Mold Vocational Training School" and "China Mold Talent Training Base", adopting the latest, most practical and internationally compatible training concepts and methods, using corporate resources, configuring the most advanced training facilities and the company's senior engineers and senior technicians as strong teaching staff, to create a brand in the field of corporate vocational education and training, and provide support for the company to continue to maintain its competitive advantage. The company implements a training scale of 300 people every year, and continuously cultivates knowledge-based and compound-skilled high-skilled talents with "excellent technology, compound skills, and diverse knowledge" that meet the company's requirements, and has built a team of high-skilled talents for the company.
11. Professional level
Hongda people firmly grasp the direction of professional technology development. In the vast field of cold stamping dies, they avoid the numerous categories and varieties of cold stamping dies and aim at motor molds for development and production. The company firmly grasps the direction of professional technology development. The company continuously innovates technology and continuously studies the application and innovation of new technologies, new processes, new materials and new equipment in motor mold products for the development and production of motor molds from small and medium-sized motor punching molds, large motor punching complex precision molds, and motor core multi-station progressive molds. It has formed mature professional technology and advanced processes for manufacturing motor molds, and formed the standardization, serialization, generalization and commercialization of motor mold products, so that the motor molds developed and produced by the company have professional characteristics and professional levels, and have the characteristic advantages of "short cycle, good quality, moderate price, and good after-sales service".
12. Standardization level
In the absence of national and industry standards for the standardization, serialization and generalization of motor mold products, "Hongda" has carried out a lot of technical basic innovation work. Combining the actual situation of the enterprise, customer requirements and drawing on advanced technologies at home and abroad, it has independently established a standardization system for motor mold products. Long-life motor silicon steel sheet cold punching dies have formed 9 standard series with nearly 2,000 mold specifications. Large, precise and complex cold punching dies for motor punching sheets have formed 6 standard series with nearly 100 mold specifications. Multi-station progressive dies for motor cores have formed 8 standard series with nearly 150 mold specifications. The standardization of motor mold products fills the gap in domestic motor mold product standards.
(1) The standardization rate of multi-station progressive dies for motor cores reached 65%; the design cycle was 5 days on average;
(2) The standardization rate of single-station compound dies for motor punching sheets reached 90%. The design cycle was 1 hour;
(3) The standardization rate of large, precise and complex cold punching dies for motor punching sheets reached 60%, with an average design cycle of 5 days and an average design cycle of 5 days.
13. Commercialization level
According to the motor punching product standards formed by the motor industry, for small and medium-sized and fractional horsepower motor punching products with a frame size of 63 to 355, starting from the customer's operating habits of motor molds, the current status of punching machine precision and production requirements, we have formulated a production stamping process and corresponding standard mold structure that meet the needs of the majority of customers, and developed and produced molds that have formed motor punching product standards in the motor industry in large quantities, forming a veritable commercial product of motor molds. It is the only company in China that goes to the counter to wholesale and retail motor mold products to motor industry manufacturers across the country. For customers, it has achieved a "zero" cycle for standard motor mold production and is deeply favored by customers.
The principle of the company's development of new products is: develop one, standardize one, and transform one, so that new products can quickly become large-scale production products. The complex and precision molds developed, such as large precision fan-shaped molds for motor punching, large block precision molds for motor punching, and multi-station progressive molds for iron cores, have successfully achieved commercialization transformation and quickly formed large-scale production products.
14. Number of CNC equipment for processing motor molds
The company has introduced and owns 4 precision CNC continuous track coordinate grinders from Moore, USA and Hauser, Switzerland, 18 slow wire cutting machines from Sodick, Japan and Charmilles, Switzerland, 3 precision machining centers from Hardinge, Taiwan, 4 large precision CNC grinders, 150 CNC fast wire cutting machines, and other CNC machining equipment, with a total of 90 CNC machining equipment.
15. Precision testing equipment
The company owns high-precision three-coordinate measuring machines from the United States (Hexagon), precision measuring imagers from Taiwan, and precision CNC continuous track coordinate grinding measurement systems from the United States and Switzerland. The high-precision three-coordinate measuring machine has a specification of 2000×900, which is the largest high-precision three-coordinate measuring machine used for motor mold testing in China.
16. Number of verification equipment
The company has introduced and owns 8 motor mold verification equipment, including Japan Yamada DOBBY 200t high-speed precision press, Xuduan 125t, 200t closed double-point high-speed precision press, Yangduan 200t closed double-point high-speed precision press, Rongcheng 250t closed single-point press, etc. The tonnage, precision and quantity of the verification equipment are the most complete in China for motor mold verification.
